The WSHT-LSX Spiral Sand Washer is a single-spiral sand washing equipment designed for efficient cleaning and dewatering of sand and fine aggregates in mining and construction applications....
The WSHT-LSX Spiral Sand Washer is a single-spiral sand washing equipment designed for efficient cleaning and dewatering of sand and fine aggregates in mining and construction applications.
With a single spiral auger rotating in a water-filled trough, the LSX series provides thorough washing action that removes clay, silt, and organic impurities from sand particles.
Single spiral design provides thorough cleaning action with effective impurity removal.
Optimized water flow design minimizes fresh water consumption during washing.
Reliable mechanical design with minimal moving parts ensures trouble-free operation.
Adjustable overflow weir allows control of water level and washing intensity.
| Model | Spiral Diameter (mm) | Trough Length (mm) | Power (kw) | Capacity (t/h) |
|---|---|---|---|---|
| LSX-762 | 762 | 4000 | 7.5 | 20-50 |
| LSX-914 | 914 | 5000 | 11 | 40-80 |
| LSX-1118 | 1118 | 6000 | 15 | 70-120 |
| LSX-1370 | 1370 | 6500 | 22 | 120-180 |
Washing of natural sand and manufactured sand for construction.
Removal of clay and impurities from aggregates in processing plants.
Washing of mineral sands and fine materials in mining operations.
Processing of silica sand for high-purity glass manufacturing.
All WSHT WSHT-LSX series equipment undergoes rigorous quality inspection and load testing before delivery. We provide comprehensive after-sales service including installation guidance, operator training, and 24/7 technical support.
专为可靠性而设计，为性能而打造。每款WSHT产品都体现了我们对质量和创新的承诺。
高强钢结构 & 精密数控加工，确保在最恶劣的采矿条件下长期可靠运行。
优化的腔体几何形状和智能设计，实现每小时最大产量并减少停机时间。
先进的工程设计可将能耗比传统设备设计降低高达20%。
现场安装、调试、操作员培训及备件供应全球可得。
